Unions/SW
Unions/SW
Spec Sheet
| Class | Nom. Size | LT in. mm |
L in. mm |
S in. mm |
|
| 3000 | |||||
| 1/8" | 1.61 40.9 |
1.24 31.5 |
|||
| 1/4" | 1.61 40.9 |
2.28 57.9 |
1.59 40.4 |
||
| 3/8" | 1.81 46 |
2.52 64 |
1.81 46 |
||
| 1/2" | 1.93 49 |
2.79 70.9 |
1.97 50 |
||
| 3/4" | 2.28 57.9 |
3.19 81 |
2.4 61 |
||
| 1" | 2.4 61 |
3.5 88.9 |
2.76 70.1 |
||
| 1 1/4" | 2.83 71.9 |
4.02 102.1 |
3.31 84.1 |
||
| 1 1/2" | 3.03 77 |
4.21 106.9 |
3.66 93 |
||
| 2" | 3.42 86.9 |
4.61 117.1 |
4.33 110 |
||
| 2 1/2" | 4.09 103.9 |
5.39 136.9 |
|||
| 3" | 4.65 118.1 |
6.22 158 |
|||
| 4" | 5.83 148.1 |
7.72 196.1 |
|||
| 6000 | |||||
| 1/8" | |||||
| 1/4" | 2.13 54.1 |
2.09 53.1 |
|||
| 3/8" | 2.32 58.9 |
2.4 61 |
|||
| 1/2" | 2.52 64 |
2.76 70.1 |
|||
| 3/4" | 2.76 70.1 |
3.15 80 |
|||
| 1" | 3.07 78 |
3.74 95 |
|||
| 1 1/4" | 3.39 86.1 |
4.25 107.9 |
|||
| 1 1/2" | 3.78 96 |
5 127 |
|||
| 2" | 4.25 107.9 |
5.83 148.1 |
|||
| 2 1/2" | 4.84 122.9 |
6.73 170.9 |
|||
| 3" | 5.24 133.1 |
7.4 188 |
|||
| 4" | |||||
