Plugs

Plugs

Spec Sheet

Nom. Size D
in.
mm
 H
in.
mm
 L
in.
mm
 LE
in.
mm
 Q
in.
mm
 F
in.
mm
 S
in.
mm
 LQ
in.
mm
 D
in.
mm
 LC
in.
mm
1/8" 0.43
10.9		 0.47
11.9		 0.28
7.1		 0.75
19		 0.28
7.1		 0.39
9.9		 0.28
7.1		 0.67
17		 0.43
10.9		 1.38
35.1
1/4" 0.63
16		 0.67
17		 0.31
7.9		 0.98
24.9		 0.39
9.9		 0.59
15		 0.28
7.1		 0.87
22.1		 0.63
16		 1.65
41.9
3/8" 0.75
19		 0.71
18		 0.35
8.9		 1.06
26.9		 0.47
11.9		 0.63
16		 0.31
7.9		 0.94
23.9		 0.75
19		 1.65
41.9
1/2" 0.87
22.1		 0.87
22.1		 0.39
9.9		 1.26
32		 0.55
14		 0.79
20.1		 0.39
9.9		 1.18
30		 0.87
22.1		 1.77
45
3/4" 1.06
26.9		 0.87
22.1		 0.43
10.9		 1.3
33		 0.63
16		 0.79
20.1		 0.43
10.9		 1.22
31		 1.06
26.9		 1.77
45
1" 1.42
36.1		 1.1
27.9		 0.47
11.9		 1.57
39.9		 0.94
23.9		 0.98
24.9		 0.51
13		 1.5
38.1		 1.42
36.1		 2.01
51.1
1 1/4" 1.81
46		 1.1
27.9		 0.59
15		 1.69
42.9		 1.1
27.9		 1.02
25.9		 0.59
15		 1.61
40.9		 1.81
46		 2.01
51.1
1 1/2" 2.01
51.1		 1.14
29		 0.63
16		 1.77
45		 1.18
30		 1.02
25.9		 0.63
16		 1.65
41.9		 2.01
51.1		 2.01
51.1
2" 2.52
64		 1.18
30		 0.71
18		 1.89
48		 1.42
36.1		 1.06
26.9		 0.71
18		 1.77
45		 2.52
64		 2.52
64
2 1/2" 2.99
75.9		 1.73
43.9		 0.75
19		 2.48
63		 1.5
38.1		 1.18
30		 0.75
19		 1.93
49		 2.99
75.9		 2.76
70.1
3" 3.62
91.9		 1.77
45		 0.79
20.1		 2.56
65		 2.05
52.1		 1.26
32		 0.87
22.1		 2.13
54.1		 3.62
91.9		 2.76
70.1
4" 4.65
118.1		 1.89
48		 1.23
31.2		 3.15
80		 2.56
65		 1.38
35.1		 1.26
32		 2.64
67.1		 4.65
118.1		 2.99
75.9
